LRS-100-12 Mean Well Power Supply 12 VDC 8.5A
72.00 ر.س
Power Supply
12VDC 8.5A
Available on backorder
Description
Enclosed Power Supply
Brand: Mean Well
Model: LRS-100-12
output: 12 VDC 8.5A
Non-PFC, most economical models
Ultra compact and 1U low profile
300VAC input surge
No load power consumption: 0.2W~0.75W
5G vibration, 70℃ operation
Operating altitude up to 5000 meters
Complete safety certificates: IEC/EN60335-1(PD3), IEC/EN61558-1, -2-16; IEC/EN/UL62368-1 and GB4943
Datasheet:
Specifications
| Shipping Weight | 0.4125 kg |
|---|---|
| Dimensions | 12.9 × 9.7 × 3 cm |
| Brand | Mean Well |
| Input Voltage (VAC) | 85~264 |
| IP Rating | not assigned |
| Model | LRS-100-12 |
| Output Current (A) | 8.5A |
| Output Power (W) | 100 |
| Output Voltage (VDC) | 12 |
| Product Dimension (LxWxH) (mm) | 129x97x30 |
| Product Weight (kg) | 0.33 |
| ROHS | ROHS |
| Safety | BIS, BSMI, CB, CCC, CE, CUL, EAC, KC, RCM, TUV-62368-1 |
| Series | LRS |
| Shape | Enclosed |
| Technology | AC/DC |
