SDR-120-48 Mean Well Power Supply 48 VDC 2.5A Din Rail
411.60 ر.س
Power Supply
48VDC 2.5A
Available on backorder
Description
DIN Rail Power Supply
Brand: Mean Well
Model: SDR-120-48
output: 48 VDC 2.5A
Metal case, slim size
94% high efficiency and complete functions
Built-in active PFC function (except SDR-75)
130%~150% peak load capability by models
Built-in DC OK relay contact (except SDR-75)
Current sharing function (SDR-480P/960)
Datasheet:
Additional information
| Weight | 0.8375 kg |
|---|---|
| Dimensions | 4 × 12.52 × 11.35 cm |
| Brand |
Mean Well |
| Input Voltage (VAC) |
90~264 |
| IP Rating |
not assigned |
| Model |
SDR-120-48 |
| Output Current (A) |
2.5A |
| Output Power (W) |
120 |
| Output Voltage (VDC) |
48 |
| Product Dimension (LxWxH) (mm) |
40×125.2×113.5 |
| Product Weight (kg) |
0.67 |
| ROHS |
ROHS |
| Safety |
BSMI ,CB ,CE ,CUL listed ,EAC ,GL ,TUV-62368-1 |
| Series |
SDR |
| Shape |
DIN Rail |
| Technology |
AC/DC |
