DC DC Converter DIN Rail 48VDC 5A DDR-240C-48
733.00 ر.س
DC DC Converter
48VDC 5A
Available on backorder
Description
DC DC Converter Din Rail
Brand:Mean Well
Model:DDR-240C-48
Output:48VDC 5A
2:1 or 4:1 wide input range
Fanless design, cooling by free air convection
Protections: short circuit / overload / over voltage / input reverse polarity / input under voltage
LED power indicator
Suitable for DIN rail types: TS-35/7.5 or TS-35/15
4KVdc I/O isolation (reinforced isolation)
Ultra slim dimensions
Datasheet:
Specifications
| Shipping Weight | 0.95 kg |
|---|---|
| Dimensions | 4 × 12.52 × 11.35 cm |
| Brand | Mean Well |
| Input Voltage (VDC) | 33.6~67.2 |
| IP Rating | not assigned |
| Model | DDR-240C-48 |
| Output Power (W) | 240 |
| Output | 48 |
| Product Dimension (LxWxH) (mm) | 40×125.2×113.5 |
| Product Weight (kg) | 0.76 |
| ROHS | ROHS |
| Safety | CB, CE, CUL, EAC, RCM |
| Series | DDR |
| Shape | DIN Rail |
| Technology | DC/DC |
