WDR-480-48 Mean Well Power Supply 48 VDC 10A Din Rail
1,300.60 ر.س
Power Supply
48VDC 10A
Available on backorder
Description
DIN Rail Power Supply
Brand: Mean Well
Model: WDR-480-48
output: 48 VDC 10A
Metal case, slim size
1∅ and 2∅ , 180~550VAC wide input
High efficiency up to 93%
Built-in active PFC function (240W & 480W)
Assemble on industrial rail TS-35 / 7.5 or 21
Built-in DC OK relay contact
Datasheet:
Specifications
| Shipping Weight | 2.125 kg |
|---|---|
| Dimensions | 8.55 × 12.52 × 12.85 cm |
| Brand | Mean Well |
| Input Voltage (VAC) | 180~550 |
| IP Rating | not assigned |
| Model | WDR-480-48 |
| Output Current (A) | 10A |
| Output Power (W) | 480 |
| Output Voltage (VDC) | 48 |
| Product Dimension (LxWxH) (mm) | 85.5×125.2×128.5 |
| Product Weight (kg) | 1.7 |
| ROHS | ROHS |
| Safety | CB, CE, CUL listed, EAC |
| Series | WDR |
| Shape | DIN Rail |
| Technology | AC/DC |
