DRS-240-24 Security Power Supply DIN Rail +24V10A +24V7.7A
1,319.00 ر.س
Security Power Supply
+24V10A +24V7.7AVDC 10A/7.7A
Available on backorder
Description
Security DIN Rail Power Supply
Brand: Mean Well
Model: DRS-240-24
Output: +24V10A +24V7.7A
Universal input 90~305VAC (277VAC available)
All-in-one function with Power supply, DC-UPS, battery charger and status monitoring in ONE compact unit
Signal and alarms design meet UL2524, NFPA1221, BS EN/EN54-4 and GB17945 requirement
Form C relay contacts and LED indicators for AC Fail, Battery Low, Charger Fail, and DC-OK
Built-in MODBus protocol, CANBus optional
Charging curve can be set with SBP-002
Datasheet:
Specifications
| Shipping Weight | 1.475 kg |
|---|---|
| Dimensions | 8.55 × 12.52 × 12.92 cm |
| Brand | Mean Well |
| Input Voltage (VAC) | 90~305 |
| IP Rating | not assigned |
| Model | DRS-240-24 |
| Output Power (W) | 240 |
| Output | +24V10A +24V7.7A |
| Product Dimension (LxWxH) (mm) | 85.5×125.2×129.2 |
| Product Weight (kg) | 1.18 |
| ROHS | ROHS |
| Safety | CB, CE, CUL, Derka (橫式), EAC, RCM |
| Series | Security – DRS Series |
| Shape | DIN Rail |
| Technology | AC/DC |
