XDR-480E-12 Mean Well Power Supply Din Rail 12 VDC 30A
511.00 ر.س
Power Supply
12 VDC 30A
Available on backorder
Description
XDR-480E-12 Mean Well Power Supply Din Rail 12 VDC 30A
Brand: Mean Well
Model: XDR-480E-12
Output: 36 VDC 13.3A
85~305Vac input with PFC
Global certificates in multi-fields: ITE 62368-1, Industrial 61558-1/-2-16, 61010 & Marine DNV, SEMI47, CID2 HazLoc approved
Ultra slim width: 30~96mm (by model)
Supports 200% peak power and 600% peak current
Built-in MODBus communication interface (XDR-240~960 Series)
Over voltage category III (OVC III)
Supports parallel operation up to 3840W (XDR-240~960 series)
-40~+85oC wide range operation temperature (> +60oC derating)
Datasheet:
Specifications
| Shipping Weight | 1.13 kg |
|---|---|
| Brand | Mean Well |
| Series | XDR |
| Model | XDR-480E-12 |
| Technology | AC/DC |
| Input Voltage (VAC) | 85~264 |
| Output Voltage (VDC) | 12 |
| Output Current (A) | 30A |
| Output Power (W) | 480 |
| Shape | DIN Rail |
| Product Dimension (LxWxH) (mm) | 125x48x125.2 |
| Product Weight (kg) | 0.9 |
| IP Rating | not assigned |
| ROHS | ROHS |
| Safety | BIS, BSMI, CB, CCC, CE, CUL-Listed, EAC, KC, RCM, TUV-62368-1, UKCA |
Datasheet
Reviews
There are no reviews yet.
