SDR-480P-48 Mean Well Power Supply 48 VDC 10A Din Rail
1,113.00 ر.س
Power Supply
48VDC 10A
Available on backorder
Description
DIN Rail Power Supply
Brand: Mean Well
Model: SDR-480P-48
output: 48 VDC 10A
Metal case, slim size
94% high efficiency and complete functions
Built-in active PFC function (except SDR-75)
130%~150% peak load capability by models
Built-in DC OK relay contact (except SDR-75)
Current sharing function (SDR-480P/960)
Datasheet:
Specifications
| Shipping Weight | 2.15 kg |
|---|---|
| Dimensions | 8.55 × 12.52 × 12.85 cm |
| Brand | Mean Well |
| Input Voltage (VAC) | 90~264 |
| IP Rating | not assigned |
| Model | SDR-480P-48 |
| Output Current (A) | 10A |
| Output Power (W) | 480 |
| Output Voltage (VDC) | 48 |
| Product Dimension (LxWxH) (mm) | 85.5×125.2×128.5 |
| Product Weight (kg) | 1.72 |
| ROHS | ROHS |
| Safety | BSMI, CB, CE, CUL listed, EAC, GL, TUV-62368-1 |
| Series | SDR |
| Shape | DIN Rail |
| Technology | AC/DC |
